LG 86” 4K LED Screen (86UH5N-M)

We stock the stunning LG86″ 4K professional LED display unit.  The 86UH5N-M has a 4K resolution, along with an impressive dynamic contrast ratio of 1,000,000:1. With 500 nits brightness and a matte screen finish, making them ideal for studio work.

This very large 86″ screen is suitable for a range of purposes including but not limited to; main event screens, relay screens, exhibition stands and more. If 86″ still isn’t big enough then check out our mammoth 98″ 4K LED display

We stock the Unicol Axia Titan Stand to go with these screens.

Specifications

Display

• Size: 86 inches
• Resolution: 4K UHD (3840 × 2160)
• Brightness (Typ.): 500 nits
• Contrast Ratio: 1,200:1 (Dynamic CR up to 1,000,000:1)
• Refresh Rate: 120 Hz
• Viewing Angle: 178° (H/V)
• Response Time: ~8 ms (G‑to‑G)
• Color Depth: 1.07 billion colors (8‑bit + FRC), BT709 95% gamut
• Surface Treatment (Haze): 25% anti‑glare
• Lifetime: Minimum 50,000 hours
• Operation: 24/7 supported, portrait or landscape orientation

Connectivity

• HDMI Inputs: 3 × HDMI 60Hz (HDCP 2.2/1.4)
• DisplayPort Input: 1 × DP 60Hz (HDCP 2.2/1.3)
• USB Inputs: 2 × USB 2.0 Type‑A
• Audio Output: 1 × Stereo mini jack
• Control & Sync: RS‑232C In/Out, RJ45 LAN, IR In

Mechanical

• Bezel: Black, uniform width approx. 13.4 mm
• Weight (Head): ~52.7 kg; Packed Weight ~65.5 kg
• Dimensions: 1,928.8 × 1,099.8 × 29.7 mm (W × H × D, without IR/handle)
• VESA Mounting: 600 × 400 mm

Features & Software

• Platform: webOS 6.0 with built‑in SoC and 16 GB eMMC memory
• Applications: PIP, PBP (up to 4), Screen Share, tile mode support (up to 15×15), content scheduling, failover, network sync, boot/no‑signal image, Crestron & Cisco Compatible, SuperSign CMS support
• Sensors: Built‑in ambient light sensor, temperature and acceleration (gyro) sensors
• Certification: CE / FCC Class B, CB/NRTL, safety/fire ratings (EN13501‑1 A1/A2, BS476 Part 7 Class 1), EPEAT/ErP compliant
